The BTB Automatic Transfer Switch integrates the programmable color screen and the switch mechanism into one single unit. It can operate electrically or manually. Its uses Molded Case switches, It has electrical and mechanical interlock protections & safety locks that stops personnel from potential injury or damage. With optional communication modules, users are enabled to control and monitor the Gen-Sets remotely and finally it is easy to install.
BTS3BC1600 / BTS4BC1600 is the 1600 Amp 3 pole and 4 pole manual and motor operated MCCB type Basic Transfer Switch. The BTS Complies with IEC60947-6-1 standards and features High Short Circuit Breaking Capacity, OCPD (Over Current Protection Device), AUX (Auxiliary Limit Switch), Bus Bars with UL approved insulation sleeve, Mechanical Interlock, and Plug-in connector for quick and fault free connection to the transformer module or controller.
High Short Circuit Breaking Capacity
Incorporate OCPD*1 Design
MCCB Has Auxiliary Limit Switch Inside
Reliable Motor -- Operated Transfer Mechanism
Molded Insulating Manual Handle
PVC-Coated Bus Bar > 3KV Insulation
With Mechanical Interlock
Includes Plug-in Connector, For Simple Hook-up to Controller
Complies with IEC60947-6-1 Requirements*2
Preassembled reinforced Aluminum Base (See picture on Right)*3
*1OCPD : Over Current Protection Device
*2IEC60947-6-1 Requirements :
IEC60947-6-1 Class CB : ATS provided with over current releases and the main contacts of which are capable of making and are intended for breaking short circuit currents.
IEC60947-6-1 Utilization Category AC-33A :
Motor loads or mixed loads including motors, resistive loads and up to 30% incandescent lamp.
*3The purpose of aluminum base design :
To prevent occurrence of eddy current (Foucault current) which reacts with steel board and cause excessive heat.
The use of aluminum base plate also greatly reduces product weight.
